    CCS GL 0.05Mpa Pneumatic Bumper for Fishing Boat Afloat Mooring Bumper

    Ask Lasest Price
    Brand Name : Jerryborg
    Model Number : 2.5m*3.5m
    Certification : ISO17357 BV CCS ABS GL LR DVN SGS KR RINA
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 pieces per year
    Delivery Time : 10-20 work days
    Price : negotiable
    • Product Details
    • Company Profile

    CCS GL 0.05Mpa Pneumatic Bumper for Fishing Boat Afloat Mooring Bumper

    CCS GL 0.05Mpa Pneumatic Bumper for Fishing Boat Afloat Mooring Bumper


    Pneumatic Bumper


    Pneumatic bumper, also called Yokohama fender, has been used in port, harbor, and maritime operations for decades since it was developed in 1958. With the development of ship technology, this product is used extensively in ship-to-ship transfer operations and ship mooring and berthing operations. It’s always regarded as a buffer.


    Fully compliant with the ISO17357 standard, Jerryborg’s bumper supplies with a variety of specifications and dimensions to meet customer’s requests and different application conditions.


    Pneumatic Bumper Advantage


    1. Shape Conformant at Inclined Compression

    Mooring bumper is made of reinforced cord layers of high elasticity and flexibility, which enable it to make it shape conformant at inclined compression during ship-to-ship operations. Compared with solid fender and foam fender, the bumper is easier to distribute the load along the ship's body or berthing structure.

    pneumatic fenders


    2. No Variation or Deformation in Performance

    Mooring bumper is filled with the air of compressive elasticity inside, the deformation caused by fatigue is absent. In the experiment below of Pneumatic fender, the performance variation will not happen if the pressure is maintained properly.

    pneumatic fenders


    Pneumatic Bumper Classification


    According to international pneumatic rubber fenders, mooring bumper systems are divided into two categories. From the appearance, there are two types of fenders:


    1.Initial Pressure 50 Kpa, P50 pneumatic fender


    2.Initial Pressure 80 Kpa, P80 pneumatic fender


    3.Type I, CTN Type, with chains and tire nets


    4.Type II, Sling Type, without chains and tire nets


    Pneumatic Bumper Structure


    ① Outer rubber layer

    This outer rubber compound is strong enough to protect the inner layer and synthetic-cord layer from the damage of external forces and severe weather conditions due to its high elasticity and abrasion resistance.


    ② Synthetic-tire-cord layer

    The Synthetic-tire-cord layer is made of synthetic-tire-cord fabrics, compared with synthetic canvas fabric and synthetic belt fabric, this reinforcement layer performs better in fatigue-resistance and pressure-holding.


    ③ Inner rubber layer

    The inner layer is designed to seal the air inside the fender.

    pneumatic fenders


    Pneumatic Bumper Application


    1.Tankers, gas carriers, and bulk carriers;


    2.Fast ferry and aluminum hull vessels;


    3.Quick response and emergency fender;


    4.As an anti-collision fender used to realign ships with coastal facilities.


    Specifications of Pneumatic Bumper


    Pneumatic 50 Standard Sizes:

    DimensionDeflection (60%)
    D (mm)L (mm)

    Reaction Force

    (KN)

    Guaranteed Energy Absorption

    (KNm)

    5001000646
    6001000748
    700100013717
    1000150018232
    1000200025745
    1200200029763
    13502500427102
    15002500499134
    15003000579153
    17003000639191
    20003500875308
    200040001000352
    250040001381663
    2500550020191131
    3000500024221357
    3000600029061293
    3300450018841175
    3300650030151814


    Pneumatic 80 Standard Sizes:

    DimensionDeflection (60%)
    D (mm)L (mm)

    Reaction Force

    (KN)

    Guaranteed Energy Absorption

    (KNm)

    5001000849
    60010009412
    700100017925
    1000150023647
    1000200033766
    1200200038689
    13502500554143
    15002500630179
    15003000756215
    17003000829262
    200035001126424
    200040001453740
    250040001817925
    2500550026531327
    3000500026891558
    3000600032751878
    3300450034761640
    3300650038292508


    For further information free to contact us.
